04 |
PF7810104 |
机头支持臂 MACHINE ARM SUPPORT ROD |
1 |
1 |
1 |
|
|
05 |
PF22840304 |
十字螺钉 SCREW |
1 |
1 |
1 |
|
|
06 |
PF7810106 |
弹性圆柱销 PIN |
1 |
1 |
1 |
|
|
07 |
PF7810107 |
橡胶缓冲垫 RUBBER CUSHION |
1 |
1 |
1 |
|
|
09 |
PF7810109 |
侧盖板衬垫 SIDE COVER |
1 |
1 |
1 |
|
|
16 |
PF7810116 |
橡皮塞 RUBBER PLUG |
1 |
1 |
1 |
|
|
17 |
PF7810117 |
橡皮塞 RUBBER PLUG |
1 |
1 |
1 |
|
|
19 |
PF7810119 |
挑线杆防护罩 THREAD TAKE-UP LEVER OIL GUARD |
1 |
1 |
1 |
|
|
20 |
PF7810120 |
十字螺钉 SCREW |
2 |
2 |
2 |
|
|
21 |
PF7810121 |
面板 FACE COVER COMPLETE |
1 |
1 |
1 |
|
|
22 |
PF7810122 |
面板衬垫 GASKET |
1 |
1 |
1 |
|
|
24 |
PF7810110 |
十字螺钉 SCREW |
4 |
4 |
4 |
|
|
25 |
PF7810125 |
油封 OIL SEAL |
2 |
2 |
2 |
|
|
27 |
PF781DB38 |
顶盖 TOP COVER |
1 |
1 |
1 |
|
|
28 |
BF700S030 |
螺钉 SCREW |
1 |
1 |
1 |
|
|
29 |
PF8420M-D3010107 |
橡皮塞 RUBBER PLUG |
5 |
5 |
5 |
|
|
30 |
BF700N03 |
六角螺母 NUT |
1 |
1 |
1 |
|
|
34 |
PF7810134 |
齿轮箱盖板 GEAR CASE COVER |
1 |
1 |
1 |
|
|
35 |
PF7810135 |
弹簧垫片 DISC SPRING |
1 |
1 |
1 |
|
|
36 |
PF7810136 |
开槽圆柱头轴位螺钉 HINGE SCREW |
1 |
1 |
1 |
|
|
38 |
PF7810138 |
手制动钩 HAND STOP LATCH |
1 |
1 |
1 |
|
|
39 |
PF7810120 |
螺钉 SCREW |
2 |
2 |
2 |
|
|
40 |
PF7810140 |
螺钉 SCREW |
6 |
6 |
6 |
|
|
43 |
PF7810143 |
橡皮塞 RUBBER PLUG |
1 |
1 |
1 |
|
|
44 |
PF781DB61 |
上盖衬垫 TOP COVER GASKET REAR |
1 |
1 |
1 |
|
|
49 |
PF7810149 |
右侧盖板衬垫 SIDE COVER GASKET REAR |
1 |
1 |
1 |
|
|
50 |
PF7810150 |
右侧盖板 SIDE COVER |
1 |
1 |
1 |
|
|
51 |
PF7810110 |
螺钉 SCREW |
7 |
7 |
7 |
|
|
52 |
PF7810152 |
油视窗衬垫 GASKET |
1 |
1 |
1 |
|
|
53 |
PF7810153 |
侧盖 SIDE COVER |
1 |
1 |
1 |
|
|
54 |
PF7810110 |
螺钉 SCREW |
4 |
4 |
4 |
|
|
55 |
PF7810155 |
侧盖板 SIDE COVER |
1 |
1 |
1 |
|
|
56 |
PF7810110 |
螺钉 SCREW |
2 |
2 |
2 |
|
|
57 |
PF7810157 |
推板 BED SLIDE |
1 |
1 |
1 |
|
|
60 |
PF7810160 |
螺柱 STUD |
2 |
2 |
2 |
|
|
61 |
PF781016101 |
LED灯(5V) LED |
1 |
1 |
1 |
|
|
62 |
SCJ5033 |
线夹 FASTENER |
1 |
1 |
1 |
|
|
63 |
PF20521118 |
线夹 FASTENER |
1 |
1 |
1 |
|
|
64 |
PF7810164 |
油视窗 OIL SIGHT WINDOW |
1 |
1 |
1 |
|
|
65 |
PF7810165 |
油视窗垫片 OIL SIGHT WINDOW GASKET |
1 |
1 |
1 |
|
|
66 |
PF7810166 |
橡皮塞 RUBBER PLUG |
1 |
1 |
1 |
|
|
67 |
PF7810167 |
橡皮塞 RUBBER PLUG |
1 |
1 |
1 |
|
|
70 |
PF7810110 |
螺钉 SCREW |
1 |
1 |
1 |
|
|
71 |
PF68425K36 |
油毡 LINOLEUM |
1 |
1 |
1 |
|
|
72 |
PF61500106 |
螺钉 SCREW |
1 |
1 |
1 |
|
|
73 |
PF20521130 |
螺钉 SCREW |
1 |
1 |
1 |
